Performance Evaluation of Vehicle Restraint Systems in the Context of Design and Installation

Shahram Tahmasseby, Deepti Muley, Bernd Wolfgang Wink

Abstract


Vehicle Restraint Systems (VRS), a necessary component of the road design, are widely implemented by transport authorities to protect vehicles from severe incidents, mainly colliding to the roadside as well as median obstacles and other potential hazards. The performance evaluation of vehicle restraint systems at the design and installation stages is largely made according to either European or American standards. The local traffic conditions and vehicle compositions in countries, which are noticeably different from Europe and North America, necessitate a customized guideline in which the design and installation of road safety barriers are more adapted to the local conditions of the country. This paper briefly reviews the main features of EN1317, and NCHRP 350/MASH standards, which are predominantly used for the design, installation, and performance evaluation of VRS in Europe and the United States respectively. Moreover, the contribution of these standards in developing the VRS guideline for the State of Qatar is explained. The study recommends customizations to the design and installation of VRS, which are presently implemented according to the guideline developed by the Public Work Authority in Qatar. The present guideline follows European as well as American standards. The recommendations are made based on empirical studies and evidence observed by undertaking a series of site visits, audits, and perform inspections of VRS components installed on Qatari roads and highways. The study findings demonstrate the performance of VRS can be enhanced by incorporating the design and selection of road safety components such as guardrails, terminals, transitions, and crash cushions at the preliminary design stage of roads and highways. This study brings about practical insights and implications for road designers, contractors, supervision teams, and road safety auditors.



Doi: 10.28991/cej-2021-03091665

Full Text: PDF


Keywords


Road Safety Barriers; Vehicle Restraint Systems; EN 1317; MASH; NCHRP 350; The State of Qatar.

References


Chang, Li-Yen, and Fred Mannering. “Analysis of Injury Severity and Vehicle Occupancy in Truck- and Non-Truck-Involved Accidents.” Accident Analysis & Prevention 31, no. 5 (September 1999): 579–592. doi:10.1016/s0001-4575(99)00014-7.

McMahon, K., and D. Ward. "Make Roads Safe: A New Priority for Sustainable Development. Commission for Global Road Safety." (2006).

Jovanović, Goran, and Rafko Atelšek. “Study of a Highly Effective and Affordable Highway Interchange - ITL Interchange.” Civil Engineering Journal 6, no. 4 (April 1, 2020): 820–829. doi:10.28991/cej-2020-03091510.

Haddon Jr, William. "Advances in the epidemiology of injuries as a basis for public policy." Public health reports 95, no. 5 (1980): 411-421.

Engineers Ireland, Vehicle restraint systems and their function: restraining and containing traffic, Nyamakope. Available online: http://www.engineersjournal.ie/2017/06/20/vehicle-restraint-systems-function/ (accessed on November 2019).

Zou, Yaotian, Andrew P. Tarko, Erdong Chen, and Mario A. Romero. “Effectiveness of Cable Barriers, Guardrails, and Concrete Barrier Walls in Reducing the Risk of Injury.” Accident Analysis & Prevention 72 (November 2014): 55–65. doi:10.1016/j.aap.2014.06.013.

La Torre, Francesca, Ceki Erginbas, Robert Thomson, Giuseppina Amato, Bine Pengal, Christian Stefan, and Graham Hemmings. “Selection of the Most Appropriate Roadside Vehicle Restraint System – The SAVeRS Project.” Transportation Research Procedia 14 (2016): 4237–4246. doi:10.1016/j.trpro.2016.05.395.

CEN 2007 EN 12767: “Passive Safety of Support Structures for Road Equipment. Requirements and Test Methods” (2007). doi:10.3403/01997635u.

DN-REQ-03034: Transport Infrastructure Ireland, the Design of Road Restraint Systems (Vehicle and Pedestrian) for Roads and Bridges. TII Publications (2019).

Budzynski, Marcin, Krzysztof Wilde, Kazimierz Jamroz, Jacek Chroscielewski, Wojciech Witkowski, Stanislaw Burzynski, Dawid Bruski, Lukasz Jelinski, and Łukasz Pachocki. “The Effects of Vehicle Restraint Systems on Road Safety.” Edited by K. Wilde and M. Niedostatkiewicz. MATEC Web of Conferences 262 (2019): 05003. doi:10.1051/matecconf/201926205003.

CEN 2010a EN 1317-1: Road restraint systems. Terminology and general criteria for test methods, (2010).

CEN 2010b EN 1317-2: Road restraint systems. Performance classes, impact test acceptance criteria and test methods for safety barriers including vehicle parapets, (2010).

FGRSV, Richtlinen für passiven Schutz an StraBen durch Fahrzeug-Rückhaltesysteme, RPS, (2009).

NCHRP-230, National Cooperative Highway Research Program Report 230: Recommended Procedures for the Safety Performance Evaluation of Highway Appurtenances. Transportation Research Board, National Research Council, Washington, DC, 1981.

NCHRP-350, National Cooperative Highway Research Program Report 350: Recommended Procedures for the Safety Performance Evaluation of Highway Features. Transportation Research Board, National Research Council, Washington, DC, (1993).

Ross, H.E., Sicking, D.L., & Zimmer, R.A. Report 350 Recommended Procedures for the Safety Performance Evaluation of Highway Features. Transportation Research Board, National Academy Press, Washington, D. C., 1993.

Mak, King K., and Roger P. Bligh. "Assessment of NCHRP report 350 test vehicles." Transportation research record 1797, no. 1 (2002): 33-37. doi: 10.3141/1797-04.

MASH. Manual for assessing safety hardware. American Association of State Highway and Transportation Officials, United States of America; (2009).

NRSS, National Road Safety Strategy 2013 – 2022. National Traffic Safety Committee, State of Qatar, (2013).

Safety Barriers Bring In Drastic Reduction In Traffic Death Rates. GulfTimes. Available online: https://www.gulf-times.com/story/517778/Safety-barriers-bring-in-drastic-reduction-in-traffic-death-rates, (accessed on December 2020).

PWA, Road Safety Barrier Systems – Accepted for use on roads managed by the Ashghal Public Works Authority (PWA), Ashghal, State of Qatar, (2015).

Dupré, Bisson and RISER Consortium, Roadside Infrastructure for Safer European Roads, D05: Summary of European Design Guidelines for Roadside Infrastructure, (2006).

Hernández, Zenaida A., Felipe Álvarez, Mar Alonso, and Luis Sañudo. “Analysis of the Test Criteria for Vehicle Containment Systems in the Standard EN 1317 Regarding the Number of Vehicles in Use.” Transportation Research Procedia 33 (2018): 315–322. doi:10.1016/j.trpro.2018.10.108.


Full Text: PDF

DOI: 10.28991/cej-2021-03091665
